| Categories | Fitting HDPE Electro Fusion |
| Brand | AMD |
| Model | Brass Outlet |
| Material | PE 100 |
| Warna | Hitam |
| Application | Water (SDR11 PN16), Gas (SDR11 PN10) |
Spesifikasi Teknik
| D | d | L | Box Sizes | Nos/Box | Kg | Type |
| 50 | 3/4 | 12 | 30x40x30 | 12 | 0.50 | B |
| 63 | 3/4 | 12 | 30x40x30 | 12 | 0.73 | B |
| 75 | 3/4 | 12 | 30x40x30 | 12 | 0.69 | B |
| 90 | 3/4 | 12 | 30x40x30 | 12 | 0.65 | A |
| 110 | 3/4 | 12 | 30x40x30 | 12 | 0.71 | A |
| 125 | 3/4 | 12 | 30x40x30 | 12 | 0.71 | A |
| 140 | 3/4 | 12 | 30x40x30 | 12 | 0.93 | A |
| 160 | 3/4 | 12 | 30x40x30 | 12 | 0.93 | A |
| 180 | 3/4 | 12 | 30x40x30 | 12 | 0.93 | A |
| 200 | 3/4 | 12 | 30x40x30 | 12 | 0.93 | A |
| 225 | 3/4 | 12 | 30x40x30 | 12 | 0.93 | A |
| 250 | 3/4 | 12 | 30x40x30 | 12 | 0.63 | C |
| 280 | 3/4 | 12 | 30x40x30 | 12 | 0.63 | C |
| 315 | 3/4 | 12 | 30x40x30 | 12 | 0.62 | C |
| 355 | 3/4 | 12 | 30x40x30 | 12 | 0.62 | C |
| 400 | 3/4 | 12 | 30x40x30 | 12 | 0.62 | C |
| 450 | 3/4 | 12 | 30x40x30 | 12 | 0.61 | C |
| 500 | 3/4 | 12 | 30x40x30 | 12 | 0.61 | C |
| 560 | 3/4 | 12 | 30x40x30 | 12 | 0.61 | C |
| 630 | 3/4 | 12 | 30x40x30 | 12 | 0.60 | C |
| 710 | 3/4 | 12 | 30x40x30 | 12 | 0.60 | C |
| 63 | 1 | 12 | 30x40x30 | 12 | 0.75 | B |
| 75 | 1 | 12 | 30x40x30 | 12 | 0.71 | B |
| 90 | 1 | 12 | 30x40x30 | 12 | 0.67 | A |
| 110 | 1 | 12 | 30x40x30 | 12 | 0.73 | A |
| 125 | 1 | 12 | 30x40x30 | 12 | 0.73 | A |
| 140 | 1 | 12 | 30x40x30 | 12 | 0.95 | A |
| 160 | 1 | 12 | 30x40x30 | 12 | 0.95 | A |
| 180 | 1 | 12 | 30x40x30 | 12 | 0.95 | A |
| 200 | 1 | 12 | 30x40x30 | 12 | 0.95 | A |
| 225 | 1 | 12 | 30x40x30 | 12 | 0.95 | A |
| 250 | 1 | 12 | 30x40x30 | 12 | 0.64 | C |
| 280 | 1 | 12 | 30x40x30 | 12 | 0.63 | C |
| 315 | 1 | 12 | 30x40x30 | 12 | 0.63 | C |
| 355 | 1 | 12 | 30x40x30 | 12 | 0.63 | C |
| 400 | 1 | 12 | 30x40x30 | 12 | 0.62 | C |
| 500 | 1 | 12 | 30x40x30 | 12 | 0.62 | C |
| 560 | 1 | 12 | 30x40x30 | 12 | 0.62 | C |
| 630 | 1 | 12 | 30x40x30 | 12 | 0.61 | C |
| 710 | 1 | 12 | 30x40x30 | 12 | 0.61 | C |
| 63 | 2 | 20 | 30x40x30 | 12 | 1.12 | B |
| 75 | 2 | 20 | 30x40x30 | 12 | 1.08 | B |
| 90 | 2 | 20 | 30x40x30 | 12 | 1.04 | B |
| 110 | 2 | 20 | 30x40x30 | 12 | 1.10 | B |
| 125 | 2 | 20 | 30x40x30 | 12 | 1.10 | B |
| 140 | 2 | 20 | 30x40x30 | 12 | 1.32 | B |
| 160 | 2 | 20 | 30x40x30 | 12 | 1.32 | B |
| 180 | 2 | 20 | 30x40x30 | 12 | 1.32 | B |
| 200 | 2 | 20 | 30x40x30 | 12 | 1.32 | B |
| 225 | 2 | 20 | 30x40x30 | 12 | 1.32 | B |
| 250 | 2 | 20 | 30x40x30 | 12 | 0.77 | C |
| 280 | 2 | 20 | 30x40x30 | 12 | 0.77 | C |
| 315 | 2 | 20 | 30x40x30 | 12 | 0.76 | C |
| 355 | 2 | 20 | 30x40x30 | 12 | 0.76 | C |
| 400 | 2 | 20 | 30x40x30 | 12 | 0.76 | C |
| 450 | 2 | 20 | 30x40x30 | 12 | 0.75 | C |
| 500 | 2 | 20 | 30x40x30 | 12 | 0.75 | C |
| 560 | 2 | 20 | 30x40x30 | 12 | 0.75 | C |
| 630 | 2 | 20 | 30x40x30 | 12 | 0.74 | C |
| 710 | 2 | 20 | 30x40x30 | 12 | 0.74 | C |
